ICA UPS SIN3000C Kapasitas 3000VA/2400W (input output 1 phase)
Rp30.525.000
Deskripsi
| Model | : | UPS SIN3000C |
| Capacity | : | 3000 VA / 2400 W |
| AC Input Voltage | : | 160 – 290 V |
| AC Input Frequency | : | 50 ± 5% Hz |
| AC Input Protection | : | MCB |
| DC Input Voltage | : | 192 V |
| DC Input Internal Battery | : | 16 x 12 V, 7 Ah |
| DC Input Protection | : | MCB |
| Charger Topology | : | SWITCHING REGULATION |
| Charger Floating Voltage | : | 217.6 V |
| Inverter Output Waveform | : | Pure Sinewave |
| Inverter Output Distortion | : | ≤2% THD |
| Inverter Output Topology | : | PULSE WIDTH MODULATION (PWM) |
| Inverter Output Voltage | : | 220 ± 2% V |
| Inverter Output Frequency | : | 50 ± 1 % Hz |
| Inverter Output Efficiency | : | ± 82 % |
| Transfer Time When AC Input Loss | : | 0 ms |
| Static Transfer Switch | : | 2 ms From Inverter To Bypass; 0 ms Back To Inverter |
| Back Up Time | : | 10 min |
| Buzzer AC Input Abnormal | : | Intermittent Sound With 2 Seconds Interval |
| Buzzer Battery Low | : | Intermittent Sound With 0.5 Second Interval |
| Operation Temperature | : | 0 – 40°C |
| Dimension (DxWxH) | : | 595 x 235 x 705 mm |
| Weight Netto | : | 81 Kg |
| Weight Gross | : | 90 Kg |
